Approx. Rs 3,400 / PieceGet Latest Price
Product BrochureProduct Details:Minimum Order Quantity | 1 Piece |
Model Name/Number | SRM-01 |
Usage/Application | Industrial |
Brand | ELECTROMARK |
Display | LED |
Features | Measurement of Surface Resistivity through LEDs. |
Storage Temp Range | 0 to 70 Deg C |
Reference Temp Range | 25 Deg C |
Weight | 160 GM |
Dimension | 135 x 70 x 30mm |
Range Selection | Auto |
Battery Type | 9V |
Low Battery Indication | Yes |
Accuracy | Half decade |
Resolution | One decade |
Output Type | LED |
Data Hold | Not applicable |
Power Source | 9V Battery |
Zero Adjustment | Not required |
Warranty | 12 Months |
Measurement Range | 10E3 to 10E13 ohms & ohms/sq |
Accessories included | Surface to Ground cord |
Test actuation | Press to ON switch |
Surface Resistivity Meter is a battery operated, wide-range, and portable instrument for measuring resistivity of effectively any flat surface. In the industry of circuit, products such as component storage bags & trays, packaging materials, table & floor mats, work bench surfaces, conveyor belts, etc., have resistance values which require to conform to rigorous specifications. Furthermore, such values are required to fall within particular limits. The instrument plays an important role in monitoring as well as checking the resistivity properties of the aforementioned products.
Also, Surface Resistivity Meter has exceptional extra feature of surface-to-ground measurement capability wherein the differential of resistivity between any chosen ground and any surface can be laid down. The surface resistivity is easily shown by a line of LEDs covering a total of 10 decades from ranging 10^3 to 10^12 ohms per square.
Additional Information:
Approx. Rs 699 / PieceGet Latest Price
Product BrochureProduct Details:Minimum Order Quantity | 1 Piece |
Usage/Application | Esd Protection |
Model Name/Number | ESD Wrist Strap Online Monitor |
Grade | Automatic |
Brand | ELECTROMARK |
Color | Black |
Packaging Type | CTN |
Length | 1.5 mtr |
Model No. | WSM-03 |
Dimensions | STANDARED |
I Deal In | New Only |
Power Supply | 9V ADAPTER |
Features | Anti static wrist strap online monitor |
Wrist Straps are the first line of defense against electrostatic charge build-up on the human body. They are designed to carry away this charge as soon as it is generated.
This model WSM-03 continuously monitors the wrist strap to detect loss of continuity between operator and monitor. Conditions such as broken coil cords and improper contact with the skin are detected instantly to alert the operator before serious and expensive ESD damage can occur. As there is no resistive return path from the wriststrap, it uses the “Capacitive AC pulse principle” to check if the operator is adequately grounded. The system is automatically activated when the wrist strap is plugged in. Continuous monitoring reduces the need for periodic checks and audits and also ensures greater security.
Additional Information:
